field-termination connector with no epoxy or polishing required

fibers to be fusion-spliced

no matching gel enables low reflection and high reliability

applicable for interconnection needing high reliability under environmental conditions

various types available such as lc, sc and fc, or pc and apc types

comply with telcordia gr-326-core service life test

u.s.pat. no.7,507,031 b2



sc, fc soc specifications

	fc/upc sc/upc	fc/apc sc/apc	fc/pc mm sc/pc mm
insertion loss	0.3db (typical)		0.1db (typical)
back reflection	<- 55db	<- 65db	<- 30db
fiber type	singlemode fiber		multimode fiber
coating / jacket type	900um, 2mm, 3mm, 4.8mm		900um, 2mm, 3mm
ferrule type	zirconia ceramic ferrule with pre-polished fiber stub



lc soc specifications

	lc/upc	lc/apc	lc/pc mm
insertion loss	0.3db (typical)		0.1db (typical)
back reflection	<- 55db	<- 65db	<- 30db
fiber type	singlemode fiber		multimode fiber
coating / jacket type	900um, 2mm, 3mm, 4.8mm		900um, 2mm, 3mm
ferrule type	zirconia ceramic ferrule with pre-polished fiber stub
